The design concept of the new fixed-frame mushroom house

The design concept of the new fixed-frame mushroom house is mainly reflected in the following aspects:

(1) Efficient use of space: Through the design of fixed bed frames, 10 to 15 layers of cultivation bed frames

are designed according to different varieties, which can maximize the cultivation area and quantity within a

limited space, thereby improving space utilization.

(2) Automatic loading and unloading: The fixed bed frame automatic loading and unloading machine system

 can automatically send the mushroom bags (bottles) after scratching to the mushroom house through the

 assembly line, and the automatic loading and unloading machine is used to complete the automatic loading

 and unloading, thereby improving production efficiency and reducing the labor intensity and cost of manual

 operation.

(3) Mobile humidifying blower: The mobile humidifying blower is used to solve the problem of uneven humidification

 caused by the original fixed humidifier in the high-density mushroom house, and improve the uniformity of

temperature and humidity.

(4) Fresh air environment control system: The fresh air entering the mushroom house is pre-processed and heated

 and cooled according to different seasons. The temperature and humidity of the fresh air are controlled to minimize

 the impact of seasonal external temperature changes on the temperature and humidity in the mushroom house,

creating a relatively stable environment for mushroom growth.

(5) Integrated environmental control system: Through PLC programming, different control programs are used for

different mushroom species. The control system can automatically adjust the environmental parameters in the

mushroom house, such as temperature, humidity, light, ventilation, etc., according to the preset control management

 parameters and the real-time environmental conditions collected by sensors, thereby providing the best growth

environment for edible fungi.
